Overview
The DSmobile DS-940DW is engineered to be truly flexible. Featuring a built-in battery, Wi-Fi and intuitive LCD panel, setup is effortless. Digitising your files whether in the office or out on the road is simple.
Enjoy scanning anywhere Truly portable, the DSmobile DS-940DW scanner has a built-in battery, so you can enjoy scanning your documents without the need to plug into a power supply. Simply take your scanner with you, scanning where it's most convenient for you.
Stay effortlessly organised Using Brother's free mobile app, viewing and sharing documents on your mobile phone or tablet is effortless. The intuitive LCD panel makes selecting and changing scan functions simple.
Convenient and space saving The DSmobile DS-940DW is small and compact, ideal where space is limited. The unique “U-path” paper feed means you are not required to have extra space behind the scanner for the document to feed-through. As the document goes in, it glides over the top of the scanner and is returned to you.
Mixed media, consistent results Designed to scan a wide range of documents including A4 documents, ID cards and receipts, makes the DSmobile DS-940DW a true work companion. The dedicated roller system, ensures your documents are smoothly fed-through, guaranteeing high-quality, digital files are created every time.
Specifications
Basic Specs
| Document Size - Single Sheet - Width | 50.8 mm to 215.9 mm |
| Document Size - Single Sheet - Length | 86.4 mm to 1,828 mm |
| Colour / Monochrome | Yes / Yes |
| 2-Sided (Duplex) Scan | Yes |
| Colour Depth - Input | 48-bit colour processing |
| Colour Depth - Output | 24-bit colour processing |
| Resolution - Optical | Max. 600 dpi × 600 dpi |
| Resolution - Interpolated | Max. 1,200 dpi × 1,200 dpi |
| Product Dimensions (Width X Depth X Height) | 319 mm × 63.1 mm × 45.4 mm |
| Weight | 0.691 kg |
| Memory Capacity | 512 MB |
Connectivity
| Connectivity | Super Speed Micro USB 3.0, Wireless LAN IEEE 802.11 b/g/n (Infrastructure Mode), IEEE 802.11 g/n (Wi-Fi Direct) |
Network
| Wireless Network Security | WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES) |
| Setup Support Utility | WPS |
Operation
| Power Source | Lithium battery USB bus-power |
| Power Consumption - Scanning | USB3.0 mode 3.6W Wi-Fi mode 4.4W |
| Power Consumption - Ready | 2.2W @Wi-Fi mode 1.5W @PC mode |
| Power Consumption - Power OFF | 0.11W |
| Temperature Operating | 5 to 35℃ |
| Humidity - Operating | 20 to 80% |
| Humidity - Storage | 10 to 90% |
Compliance
| TWAIN Compliant - Windows® | Windows® 7 SP1 / Windows® 8.1 / Windows® 10/ Windows Server® 2012 / Windows Server® 2012 R2 / Windows Server® 2016 / Windows Server®2019 |
| TWAIN Compliant - Macintosh | macOS v10.12.x/10.13.x/10.14.x |
